PRO Single Port USB to Serial Adapter with Activity LED 3ft

Part # USA-FTDI-A36
$19.67

Status: Available

Windows 10 USB to serial RS232 adapter with FTDI chip is adeal for your 36 inch connection from your host USB port, the serial adapter has a 300bps to 1Mbps Baud Rate and built-in statics and electrical surge protection up to 600W.

Compatibility

Product Documentation & Drivers

PRO Single Port USB to Serial Adapter with Activity LED 3ft

Part # USA-FTDI-A36
Product Rating:
4.85 out of 5 stars
Product Image
  • Product Image Thumbnail
  • Product Image Thumbnail
  • Product Image Thumbnail
  • Product Image Thumbnail
  • Product Image Thumbnail
$19.67

Compatibility

Documentation

This USB to Serial Adapter is supported in Windows 10

The USB to serial adapter protocol RS-232 has been widely used since the late 60’s and a standard in computer equipment use since the 1990’s, it is very reliable. The USB to serial adapter is generally used in industrial, office, or business environments. It is also commonly used as a consumer product for connecting USB serial products to personal computers. The RS232 USB to serial adapter is most often only used in industrial environments, labs and similar facilities since the protocol is very useful in these environments.

The High-end quality processor chip FT232RL from FTDI Semiconductors which is one of the best and most reliable USB serial processors on the market is used in converting to the serial signal; the converter also includes a ZT232E RS232 transceiver from ZyWyn USA. (Pictured Below)



PRO Single Port USB to Serial Adapter with Activity LED Circuit Board view



Features & Specifications:

  • Indication LED’s for Power, TX and RX
  • No power supply needed, plug and play
  • No IRQs, DMA or required. No IRQ Conflicts
  • 3 feet (1 meter) cable
  • Baud rate: 300bps to 1Mbps
  • RS232 output power: -5.7 to +5.7VDC
  • USB 1.1 and 2.0 compliant
  • Automatic send data control
  • Auto detection of data speed
  • Zero delay automatic transmission
  • Built-in static and surge protection up to 600W
  • 5 year warranty
  • Windows 10 support

OS Support:

  • Win98, Me, XP, 2000, 2003, CE, Vista, 7, 8, 10
  • Linux
  • Mac OS 10.X

Package Contents:

  • USB to Serial Adapter with Activity LED
  • Latest FTDI driver (available as download)
  • GM-FTDI-A36 Product Manual (available as download)

Sometimes you need a product in a flash and just want to verify an item is in stock. Other times you have a specific question regarding a product, shipping method, or your order. Use the form below and we will help. Please refrain from spam, we only log this information to our database for 24-hours and then it's gone.

Specifications

Manufacturer: GearmoWarranty: 1 YearAvailability: Available
Barcode: 729440625993Ship Weight: 0.16Condition: New
Part Number: USA-FTDI-A36Color: BlueLength/Size: 36 in
Port Count: 1Port Type: Male DB9 /W NutsInput Voltage: Unspecified or N/A
Temperature(Op): -40 to 85 CESD Protection: 15KVSerial Modes: RS232
LEDs: ArrayIsolation: --Chip: --

Specifications

Manufacturer: Gearmo
Barcode: 729440625993
Part Number: USA-FTDI-A36
Warranty: 1 Year
Ship Weight: 0.16
Color: Blue
Availability: Available
Condition: New
Port Count: 1
Port Type: Male DB9 /W Nuts
Input Voltage: Unspecified or N/A
Temperature(Op): -40 to 85 C
ESD Protection: 15KV
Isolation: --
Serial Modes: RS232
LEDs: Array
Chip: --
